MTL SD16R High-Bandwidth Surge Protector | MTL Instruments
$ 96.45
MTL SD16R High-Bandwidth Signal Surge Protection OverviewThe MTL SD16R represents a precision-engineered surge protection device (SPD) designed by MTL Instruments. Engineered for high-frequency signal integrity, this module employs a hybrid line-to-line and line-to-screen protection circuit. Engineers utilize the MTL SD16R to safeguard critical instrumentation loops from hazardous transient surges in industrial control environments. Oiltech Controls recommends this unit for high-speed data and analog signal applications requiring sub-nanosecond response times.Technical Specifications & Engineering DataManufacturer: MTL InstrumentsModel: MTL SD16RProtection Type: Hybrid (Line-to-Line & Line-to-Ground)Response Time: < 1nsNominal Voltage (Un): 16V DC / 11V ACMax. Continuous Operating Voltage (MCOV): 17VBandwidth: 50MHz (High Bandwidth Feature)Voltage Protection Level: < 25V (@1kV/µs)Residual Voltage (@isn): 40VSeries Resistance: 4.7 Ω/lineNominal Current: 400mAOperating Humidity: 5% to 95% RH (Non-condensing)Device Suitability & Oiltech Controls InsightTarget Applications: Ideally suited for high-speed pressure transmitters, flow meters, and sensitive process control loops.Mounting: Optimized for standard 35mm x 7.5mm or 35mm x 15mm DIN-rail installation.Terminal Capacity: Equipped with robust terminals supporting up to 2.5mm² (12 AWG) conductors.Oiltech Insight: We suggest the MTL SD16R for loops where bandwidth preservation is as critical as surge immunity, particularly in noisy EMI environments.Maintenance Tip: Periodic loop continuity tests verify that series resistance remains within nominal limits after exposure to heavy electrical transients.Logistics and Warranty InformationShipping Lead Time: Fast dispatch within 24-28 hours upon order confirmation.Logistics Partners: Global delivery via trusted carriers: FedEx, UPS, and DHL.Warranty: This product includes a 12-month quality guarantee against manufacturing defects.Technical Inquiries: Contact our team at [email protected]: For immediate logistics or technical assistance, contact us via WhatsApp: 86 158 8020 0923.Expert FAQ & Selection GuideQuestion: How does the 50MHz bandwidth impact my signal application?Answer: The high bandwidth ensures that the MTL SD16R does not attenuate high-frequency signals, making it perfect for rapid data protocols.Question: Can I install this device in existing enclosures with limited space?Answer: Yes, its slim DIN-rail form factor is designed to maximize density within standard control panels.Question: Does the 4.7Ω series resistance affect my loop calibration?Answer: This minimal resistance is generally negligible; however, adjust your loop power supply output slightly to account for the voltage drop at max load.Question: Is the ground connection critical for the surge protection performance?Answer: Absolutely; ensure the DIN-rail is securely bonded to a high-quality, low-impedance common earth point for effective surge dissipation.Question: How do I identify if the MTL SD16R has reached the end of its service life?Answer: Check for a significant increase in leakage current or persistent signal errors, which may indicate that the internal protection components have aged.Copyright © 2026 Oiltech Controls Limited. https://www.oiltechcontrols.com/ All rights reserved.
